142 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 9 Troubleshoot the System
Isolate the Anomaly
This section provides general troubleshooting information to assist you when
trying to isolate anomalies.
Check for Adequate Power
A terminal that does not receive adequate power could result in unpredictable
behavior. Refer to Appendix
A, Specifications, for power requirements.
Check Indicators at Startup
When the terminal starts, the fault and comm indicators flash on and off, then
the comm indicator flashes to signal progress during startup. When startup is
complete, the comm indicator remains on, and is controlled by the
communication driver or application. The comm indicator typically flashes when
communication is active.
If the indicators remain off, the power supply or logic module has failed. Check
the power cable:
• If the power is not within range, replace the power supply.
• If the power is within range, replace the logic module.
The table shows indicator states if the terminal powers on and stops during
startup.
Table 60 - Indicator States if Terminal Stops During Startup
Fault (Red)
Indicator
Comm (Green)
Indicator
Description
Blinking Off
Recoverable firmware error. Last firmware download failed.
Reload the firmware using the Firmware Upgrade Wizard (FUW).
On
Off Non-recoverable hardware fault with logic module.
Replace the logic module.
Blinking Non-recoverable hardware fault with display module.
Replace the display module.
