130 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 7 Terminal Connections
Software and Firmware Requirements
The software and firmware must be installed on the development computer and
the PanelView Plus 6 terminal to configure and communicate with an
Allen-Bradley controller on a ControlNet network.
Table 57 - ControlNet Unscheduled Communication
Software/Firmware Version/Revision Requirements
FactoryTalk View Studio Version 6.0 or later
FactoryTalk View Machine Edition Runtime Version 6.0 or later
ControlNet module firmware 2711P-RN15S, Series A, Rev A (firmware
revision 2.07 or later)
(1)
(1) This applies to terminals that are ordered as pre-configured units with the ControlNet module.
Table 58 - ControlNet Scheduled Communication
Requirements Version Requirements
FactoryTalk View Studio Version 6.0 or later
FactoryTalk View Machine Edition Runtime Version 6.0 or later
RSNetWorx for ControlNet Version 5.11 or later
RSLogix 5000 Version 18.0 or later
ControlNet module firmware 2711P-RN15S, Series A, Rev C (firmware
revision 3.08 or later)
(1)
(1) This applies to terminals that are ordered as preconfigured units with the ControlNet module.
WARNING: The ControlNet communication module, cat. no.
2711P-RN15S or 2711P-RN15SK, will not run with FactoryTalk View ME
firmware
revision 3.20.04 or earlier. All ControlNet modules with revision
3.07 firmware must be upgraded to
revision 3.08 or later; otherwise,
outputs may turn on an indeterminate state.
