64 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 4 Configuration Mode
Configure the Screen Saver
The screen saver on the terminal activates after an idle period using a specific
intensity. The default idle timeout is 10 minutes. You can adjust the idle timeout
and intensity level for the screen saver, disable the screen saver, and enable or
disable the screen saver bitmap.
1. Select Terminal Settings>Display>Screen Saver.
2. Press the Screen Saver button to select an idle timeout for activating the
screen saver.
To disable the screen saver, select the Disabled option.
3. Increase or decrease the brightness intensity of the screen saver by pressing
the up and down cursor buttons.
4. Press the Advanced Settings button to access the bitmap option.
• Select the Screen Saver Image button to enable or disable the screen
saver bitmap.
• Press OK to return to the previous.
5. Press OK to exit and return to the terminal settings.
Enable or Disable the Screen Cursor
The terminal has a screen cursor that you can enable or disable.
1. Select Terminal Settings>Display>Cursor.
2. Press the Enable Cursor button to enable or disable the cursor.
3. Press OK to exit and return to Terminal Settings.
