28 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 2 Install Terminal
Required Tools
These tools are required for panel installation:
• Panel cutout tools
• Small, slotted screwdriver
• Torque wrench for tightening the terminal mounting clips
Clearances
Allow adequate spacing around the terminal, inside the enclosure, for adequate
ventilation. Consider heat produced by other devices in the enclosure. The
ambient temperature around the terminals must be between
0…55 °C (32…131 °F).
These minimum clearances are required for ventilation:
• Top clearance: 51 mm (2 in.)
• Bottom clearance: 102 mm (4 in.)
• Side clearances: 25 mm (1 in.)
• Back clearance: 25 mm (1 in.)
Minimum side clearance for inserting an SD card is 102 mm (4 in.).
Panel Cutout Dimensions
Use the full size template shipped with your terminal to mark the cutout
dimensions.
Terminal Type Height, mm (in.) Width, mm (in.)
700 Keypad or Keypad and Touch 167 (6.57) 264 (10.39)
700 Touch 154 (6.08) 220 (8.67)
1000 Keypad or Keypad and Touch 224 (8.8) 375 (14.75)
1000 Touch 224 (8.8) 305 (12.00)
1250 Keypad or Keypad and Touch 257 (10.11) 390 (15.35)
1250 Touch
(1)
(1) Also applies to High-bright display module, cat. no. 2711P-RDT12H also.
257 (10.11) 338 (13.29)
1500 Keypad or Keypad and Touch 305 (12.00) 419 (16.50)
1500 Touch 305 (12.00) 391 (15.40)
