Chapter
4
Configuration Mode
Chapter Objectives
This chapter shows how to use FactoryTalk View ME Station on your terminal to
load and run applications, configure startup options, access the Windows
Explorer desktop, configure communication, and perform other terminal
operations.
Access Configuration Mode
The terminals use onboard software, FactoryTalk View ME Station, to perform
and configure terminal operations. When you reset the terminal, one of these
actions occur, depending on the configured startup option:
• FactoryTalk View ME Station is launched, which is the Configuration
mode of the terminal (closed system). This is the initial default.
• The Windows Explorer desktop is launched (open system).
• FactoryTalk View Machine Edition .mer application is set to run (closed
system).
From Windows Explorer desktop, you can access the Configuration mode of the
terminal by double-clicking the FactoryTalk View ME Station icon on the
desktop.
Topic Page Topic Page
Access Configuration Mode 41 Configure Print Options 68
Terminal Settings 44 Check Integrity of Application Files 70
Load and Run Application 46 Configure Diagnostics 71
Startup Options 47 View and Clear the System Event Log 72
Desktop Access 50 System Information 73
Communication Setup 54 Enable or Disable the Alarm Display 75
Ethernet Network Connections 56 Time and Date Settings 76
File Management 60 Regional Settings 78
Display Settings 63 Font Linking 82
Input Device Settings 65
IMPORTANT
To access Configuration mode from a running application, press the Goto
Configuration Mode button. This button is added to application screens
in FactoryTalk View Studio software during application development. The
application stops running but is still loaded.
