MP-20x Telephone Adapter 136 Document #: LTRT-50609
User's Manual
11.2 LAN-WAN Bridging
WAN bridge creates a bridge over WAN and LAN devices. In this way, PCs on the MP-
20x's LAN side can get IP addresses that are known on the WAN side.
Note: Currently, the MP-202C model does not support LAN-WAN bridging.
11.2.1 Creating with the Connection Wizard
¾ To configure an existing bridge or create a new one:
1. From the sidebar menu, click the Network Connections menu, and in the screen
'Network Connections' click the New Connection link; the 'Connection Wizard' screen
opens.
Figure 11-23: Connection Wizard Screen
