6
Before Use
Optional supplies
Principal parts
b Memo:
• Since power is supplied to the USB card writer module through the USB connection to the computer,
there is no power supply cable or power switch.
• Be sure to keep original cards away from high humidity, direct sunlight, static electricity and strong
shocks. Furthermore, do not bend the cards.
a Note:
The only original cards that can be used with this USB card writer module are those like the one enclosed
or optional original cards of the same type.
Original card
USB connector
Connect to the computer.
LED indicator
This indicator lights up when the unit is turned on,
and flashes when the USB card writer module is
communicating with the computer.
a Note:
Never remove an original card or unplug the
USB cable while this indicator is flashing.
Card slot
Insert an original card/embroidery
card here.
PeDesignV6Eng.book Page 6 Thursday, July 8, 2004 11:59 AM
