232
Design Database
Outputting as a CSV file
A .csv file containing the sewing information (file
name, dimensions, number of stitches, number of
colors, file path, file properties (.pes files only) and
the names of thread colors) for selected embroidery
patterns can be outputted.
1. In the folder pane, select the folder containing
the embroidery patterns that you want to
catalog.
2. Click File, then Create CSV.
→ A Save As dialog box similar to the one
shown below appears.
3. Select the drive and the folder, and then type
in the name of the .csv file.
4. Click Save.
→ A CSV file containing the sewing informa-
tion for the embroidery patterns is output-
ted to the selected folder.
PeDesignV6Eng.book Page 232 Thursday, July 8, 2004 11:59 AM
