© Cesab 8 – 2 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Tow using a tow truck and tow wagon:
1. Lift the truck onto the tow wagon. See the instructions under Lifting a
truck.
2. Connect the truck to the wagon.
3. Drive with care.
4. Lift off the truck according to the instructions under Lifting a truck.
8.3 Emergency driving mode
If the truck for some reason stops operating and remains immobile in an
unsuitable place, it is possible to active the emergency travel mode to move
the truck out of the way (max. 1.3 km/h). In this mode, it is possible to lower
and lift the forks.
1. Make sure that the truck is switched off. Enter your PIN code.
2. Press and then release the horn button. “Info“ is shown on the display.
3. Turn the speed control several times until “Ed” is shown on the display.
4. Press and then release the horn button to select.
5. All lamps flash and “SLO” is shown on the display.
It is now possible to drive the truck, but exercise extreme caution. It is not
possible to brake suddenly by raising the steering unit.
If the truck is on an incline, be even more careful when using the emergency
travel mode. If you apply too much throttle, there is a risk the truck will roll
away. To stop the truck, turn the sped control in the opposite drive direction.
Note:
Some errors block emergency travel mode. You then cannot obtain
information on the error.
