CESAB S214L User Manual

© Cesab 4 – 10 T Code(s): 841, 842, 843
Repair manual: Operation and connection sequencesModel(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
4.15 Click-2-Creep
4.16 Turtle function (option)
Event Click-2-Creep
Preceding event
Start the truck.
Action(s)
Quick double-actuation of the speed control to
activate the function.
Set the tiller arm in the vertical position and drive
the truck at creep speed
(2.5 km/h).
Influencing elements
Main contactor [Q10].
Setting of factory parameter 1002.
Resulting conditions
[T1:OUT.BRAKE RELEASE] goes {low}.
Brake coil [Q1] is activated, and the mechanical
brake is released.
Power is fed to the drive motor's field coils (S2 +ve
and S1 -ve).
Pulsed current feed to drive motor rotor is
proportional to speed control actuation. “SLO” is
displayed (flashes).
Event Turtle function (option)
Preceding event
Tiller arm is lowered to the drive position.
Action(s)
Press [S206] to activate this function.
Turn the speed control in either direction.
Influencing elements
Main contactor [Q10].
Option button 1 [S206].
Setting of operator parameter 7 and service
parameter 202.
Resulting conditions
[T1: OUT. BRAKE RELEASE] goes {low}.
Brake coil [Q1] is activated, and the mechanical
brake is released.
Power is fed to the drive motor's field coils (S2 +ve
and S1 -ve).
Pulsed current feed to drive motor rotor is
proportional to speed control actuation. The
maximum travel speed is determined by operator
parameter 7. “SLO” is displayed (lit continuously).
