© Cesab 24 – 4
T Code(s):
841, 842, 843
Repair manual:
Technical data
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
24.2 S212L, S214L, S220D
Model S212L S214L S220D
Drive motor
Type Iskra AML7109
Power, kW 1.5
Duty cycle S2-60 min
Weight, kg 10.5
Brake
Type Warner PK10
Braking force, Nm 15
Power, W 51/13
Resistance, coil, Ω 10.5-12.0
Nominal gap in actuated position,
mm
0.2-0.55
Minimum thickness of brake disc,
mm
7.9
Thickness of new brake disc, mm 8.2
Transmission/gear mechanism
Type Kordel Genius 5.72.02.1
Gear ratio 30.204
Oil volume, litres 0.8
Oil See section “23.2 Lubricants specification”.
