© Cesab 15 – 10 T Code(s): 841, 842, 843
Repair manual: Hydraulic system 6000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
15.7 Adjusting the pressure limiting valve
Valve location
The truck must be able to handle the rated load on the forks.
Place a rated load on the forks and verify that the truck is able to lift it.
If the truck cannot lift the rated load:
1. Pry off the sealing cap (a) attached to the pressure limiting valve using a
screwdriver.
2. Remove the protective cover (b) (17 mm) by turning it anti-clockwise.
Remove the protective cover and the washer housed inside it.
3. Loosen the locking nut (c) (17 mm) by turning it anti-clockwise.
