CESAB S214L User Manual

© Cesab 4 – 9 T Code(s): 841, 842, 843
Repair manual: Operation and connection sequencesModel(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
4.13 Fork lowering
4.14 Support arm lowering (S212L, 214L, S220D)
Event Fork lowering
Preceding event
Start the truck or commence fork lifting.
Action(s)
Press the fork lowering button [A5:S321].
Influencing elements
Main contactor [Q10].
Fork lowering button [A5:S321].
Resulting conditions
[T1:OUT. LOWER VALVE] goes {low}, the
hydraulic lowering valve [Q4] opens.
Event Fork lowering
Preceding event
Start the truck or commence fork lifting.
Action(s)
Press the support arm lowering button [A5:S321].
Influencing elements
Main contactor [Q10].
Support arm lowering button [A5:S321].
Resulting conditions
[T1:OUT. LOWER VALVE] goes {low}, proportional
valve [Q4] opens.
