© Cesab 4 – 7 T Code(s): 841, 842, 843
Repair manual: Operation and connection sequencesModel(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
4.9 Emergency reversal
4.10 Fork lifting
Event Emergency reversal
Preceding event
Driving in the drive wheel direction
Action(s)
When driving in the drive wheel direction, the emergency
reversal button is pressed
Influencing
elements
Emergency reversal
Resulting
conditions
The Hall sensor [A5:S317] is immediately activated.
The card [A5] interprets this signal as a command to
the transistor regulator [T1] to run the drive motor at
a reduced speed in the fork direction as long as the
button is depressed. The normal drive command
signal received from [L1] is blocked until [L1] is
released and returns to neutral position.
Event Fork lifting
Preceding event
Start the truck.
Action(s)
Press the fork lift button [A5:S320].
Influencing elements
Main contactor [Q10].
Fuse [F1].
Lift forks button [A5:S320]
Battery status OK (battery discharge indicator > 0
or battery charge > 20 %).
Resulting conditions
Pump motor [M3] starts.
