© Cesab 13 – 10 T Code(s): 841, 842, 843
Repair manual: Tiller arm 4000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
13.5.5 Replacing the tiller arm handle
Removing the tiller arm handle
• Remove the upper cover. Page 13–8
1: Remove the cable bracket/handle in the tiller arm.
Fitting the tiller arm handle
1: Fit the handle/cable bracket.
Note: Mount the wiring harness so that it does not get pinched.
• Fit the upper cover. Page 13–9
