© Cesab 22 – 3
T Code(s):
841, 842, 843
Repair manual:
Tools
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
22.2 AMP connectors
PT = Power Timer (4.8. 5.8. 6.3 mm)
JPT = Junior Power Timer (2.8 mm)
MPT = Micro Power Timer (1.5 mm)
Figure Number Use
151080 (PT) Removal tool for pins/
sleeves
213296 (JPT) Removal tool for pins/
sleeves
213298 (MPT) Removal tool for pins/
sleeves
1=163787 (JPT)
2=163788 (JPT)
1=213336 (MPT)
2=213337 (MPT)
Crimping tool (sleeves only)
1=213336 (JPT)
2=213549 (JPT)
Crimping tool for fitting pins
For 0.5–2.5 mm
2
