© Cesab 21 – 1
T Code(s):
841, 842, 843
Repair manual:
Hydraulics chart
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
21. Hydraulics chart
SA
1
5
6
4
3
2
Support arms
Duplex Hilo
Triplex Hilo
Simplex/
Duplex tele
Duplex tele
panoramic
F
Q23 Q22
Q4
Max 230 Bar
7
8
9
10
11
12
14
13
