© Cesab 10 – 8 T Code(s): 841, 842, 843
Repair manual: Electric drive motor 1700 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
10.6 Installing the temperature sensor
1. Cut off the wiring to the broken temperature sensor, and splice on the
new one
2. Position the new temperature sensor on the motor.
3. Carefully clean the area and make sure all surfaces are dry.
4. Apply plastic steel by pushing out a string that is half the length of the cur-
ing agent compared to the putty, then carefully mix the two (be careful not
to mix a larger amount than will be used in 5 minutes).
5. Apply a layer of plastic steel, at least 4 mm thick, and make sure the re-
paired surface has an overlap of at least 2 cm.
6. Secure the steel plastic with masking tape and allow it to cure.
7. Remove the masking tape.
The temperature sensor should now be completely covered by plastic
steel.
8. Following curing, it is recommended to apply another layer of plastic
steel.
