© Cesab 15 – 8 T Code(s): 841, 842, 843
Repair manual: Hydraulic system 6000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
15.5 Hose rupture valve
15.5.1 Replacing the hose rupture valve
The hose rupture valve is built into the cylinder/hydraulic hose bracket.
Note:
When fitting these components, it is very important that no dirt etc. enters
the hydraulic system.
1: Detach the hydraulic hose from the cylinder and plug the connection.
2: Unscrew the hydraulic hose bracket/hose rupture valve from the
cylinder.
3: The new hose rupture valve should be torque tightened to 40 +5 Nm.
