2-356
Catalyst 3560 Switch Command Reference
78-16405-05
Chapter 2 Catalyst 3560 Switch Cisco IOS Commands
show cable-diagnostics tdr
show cable-diagnostics tdr
Use the show cable-diagnostics tdr privileged EXEC command to display the Time Domain Reflector
(TDR) results.
show cable-diagnostics tdr interface interface-id [ | {begin | exclude | include} expression]
Syntax Description
Command Modes Privileged EXEC
Command History
Usage Guidelines TDR is supported only on 10/100/1000 copper Ethernet ports. It is not supported on 10/100 ports or on
SFP module ports. For more information about TDR, see the software configuration guide for this
release.
Expressions are case sensitive. For example, if you enter | exclude output, the lines that contain output
do not appear, but the lines that contain Output appear.
Examples This is an example of output from the show cable-diagnostics tdr interface interface-id command on
a switch other than a Catalyst 3560G-24PS or 3560G-48PS switch:
Switch# show cable-diagnostics tdr interface gigabitethernet0/2
TDR test last run on: March 01 20:15:40
Interface Speed Local pair Pair length Remote pair Pair status
--------- ----- ---------- ------------------ ----------- --------------------
Gi0/2 auto Pair A 0 +/- 2 meters N/A Open
Pair B 0 +/- 2 meters N/A Open
Pair C 0 +/- 2 meters N/A Open
Pair D 0 +/- 2 meters N/A Open
interface-id Specify the interface on which TDR was run.
| begin (Optional) Display begins with the line that matches the expression.
| exclude (Optional) Display excludes lines that match the expression.
| include (Optional) Display includes lines that match the specified expression.
expression Expression in the output to use as a reference point.
Release Modification
12.2(20)SE3 This command was introduced.
