2-513
Catalyst 3560 Switch Command Reference
78-16405-05
Chapter 2 Catalyst 3560 Switch Cisco IOS Commands
show power inline
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----
Fa0/1 auto on 6.3 IP Phone 7910 n/a 15.4
This is an example of output from the show power inline consumption default command on all PoE
switch ports:
Switch> show power inline consumption default
Default PD consumption : 15400 mW
Related Commands
Table 2-30 show power inline interface Field Descriptions
Field Description
Admin Administration mode: auto, off, static
Oper Operating mode:
• on—the powered device is detected, and power is applied.
• off—no PoE is applied.
• faulty—device detection or a powered device is in a faulty state.
• power-deny—a powered device is detected, but no PoE is available, or the
maximum wattage exceeds the detected powered-device maximum.
Power The supplied PoE in watts
Device The device type detected: n/a, unknown, Cisco powered-device, IEEE
powered-device, <name from CDP>
Class The IEEE classification: n/a, Class <0–4>
Available The total amount of PoE in the system
Used The amount of PoE allocated to ports
Remaining The amount of PoE not allocated to ports in the system. (Available – Used =
Remaining)
Command Description
logging event
power-inline-status
Enables the logging of PoE events.
power inline Configures the power management mode for the specified PoE port or for all
PoE ports.
show controllers
power inline
Displays the values in the registers of the specified PoE controller.
