DVP15MC11T Operation Manual
_8
8.6.2 TOF
FB/FC
Explanation
Applicable
model
FB
TOF is used for the off delay. DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
In Timer input
Input
Controls the timer to start or reset TRUE or FALSE
PT Set time
Input
Set the time from when the timer starts
until Q changes to TRUE
Q Timer output
Output
Q is FALSE when the set time PT is
reached.
TRUE or FALSE
ET Elapsed time
Output
Elapsed time from the time when the timer
starts to current time.
 T#0ns ~ 213503d23h34m33s709ms551us615ns
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
In
●
PT
●
Q
●
ET
●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation

The TOF instruction is defined as the function of a timer for the OFF delay.

When In is TRUE, Q is TRUE. When In changes from TRUE to FALSE, the timer starts to measure
the time and the value of ET increases accordingly. At the moment, Q remains TRUE. When ET
equals PT, Q is FALSE and the timer stops measuring time. When In is set to TRUE, ET is reset and
Q changes to TRUE again.
 Precautions for Correct Use
When the output value of ET reaches the set value of PT, the timer stops measuring time. ET is reset
to 0 (0ns) when In changes from FALSE to TRUE.
TOF
EN ENO
Q
TOF_instance
In
PT
ET
8-42
