DVP15MC11T Operation Manual
_5
5.1 Dimensions
5.1.1 Profile and Dimensions of DVP15MC11T
CAN
ERR
1
RUN
ERR
2
RUN
00
10
00
01
11
01
02
12
02
03
13
03
04
14
04
05
15
05
06
16
06
07
17
07
128
EXTENSION
PORT
110
68.4
116.2
Unit: mm
5.1.2 Dimensions of Left-side and Right-side Extension Modules
 See the following dimension figure of a left-side extension module by taking DVPCOPM-SL for example.
The length, width and height of all left-side modules are the same as that of DVPCOPM-SL.
96 90
33.1 60
Unit: mm
 See the following dimension figure of a right-side extension module, which takes DVP04AD-S for
example. The length, width and height of all left-side modules are the same as that of DVP04AD-S.
5-2
