DVP15MC11T Operation Manual
_4
No. Module name
Input data
length
Output data
length
Extension type
10 DVP32SN11TN - 32 bits Pin-connector output
11 DVP08ST11N 8 bits - Digital switch
12 DVP04AD-S 4 words -
Analog input
13 DVP06AD-S 6 words -
14 DVP04DA-S - 4 words
Analog output
15 DVP02DA-S - 2 words
16
DVP06XA-S
4 words
2 words
Analog input and analog output
17 DVP04PT-S 4 words -
Sensor
(Model: PT100)
18 DVP06PT-S 6 words -
19 DVP04TC-S 4 words -
Sensor
(Model: J, K, R, S, T thermocouples)
4.4.2 Allocation of Right-side Extension Module Addresses
DVP15MC11T can connect Slim-series extension modules to its right side and max. 240 digital input points
and 240 digital output points are connectable. Max. 8 special modules are connectable such as analog
modules, temperature modules and pulse modules. Up to 14 digital modules and special modules at most are
connectable to the right side of DVP15MC11T.
 Input point number and output point number of right-side digital extension modules
The input point number and output point number of the digital extension modules connected to the right of
DVP15MC11T start from 2.0. For example, the input point for the first digital module starts from %IX2.0 and
the output point starts from %QX2.0. It is counted as 8 points if the number is less than 8.
Digital input points and output points are numbered as below: (Octal)
%IX2.0 ~%IX2.7,......, %IX16.0 ~%IX16.7,......, %IX31.0 ~ %IX31.7
%QX2.0 ~ %QX2.7,......, %QX16.0 ~ %QX16.7,......, %QX31.0 ~ %QX31.7
 About the right-side special module and serial number
 The right-side extension modules such as analog modules, temperature modules and pulse
modules are regarded as special modules.
 The serial number of the first special module to the right side of DVP15MC11T is 0; the serial
number of the second one is 1, and so on. Maximum 8 special modules can be connected. The start
address for input of the right-side special module is %MW10000 and the start address for output of
the right-side special module is %MW10500.
 DVP15MC11T can directly read and write the right-side module parameters through the hardware
configuration interface of the software. Also, it can grant a value to an address or grant a value to a
variable with which an address is combined in a program to read and write right-side module
parameters.
4.5 Connectable Servo Drives
There are many models for ASDA-A2-series servo drives. ASDA-A2-XXXX-M model supports CANopen
communication. Only ASDA-A2-XXXX-M servo drives can be used to build CANopen motion control network
through connecting the motion port of DVP15MC11T. The connection between DVP15MC11T and the servo
drive can be made with UC-CMC003-01A or UC-CMC005-01A cable through CN6 port.
4-4
