8.15.4 ImmediateOutput
FB/FC
Explanation
Applicable
model
FC
ImmediateOutput is used for the immediate refresh of output points. DVP15MC11T
ImmediateOutput
EN ENO
Output
Num
 Parameters
Parameter name Meaning
Input/
Output
Description Valid range
Output
Start output
point
Input Start output point 0~7
Num Number Input
Number of output points for immediate
refresh
1~8
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
Outp
ut
●
Num
●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation

The ImmediateOutput instruction is used for refreshing current status of internal output
point %QX0.0~%QX0.7 to external hardware output point. If the ImmediateOutput instruction does
not exist, the controller refreshes internal output point status to external hardware output point. The
status of %QX0.0~%QX0.7 is decided by other instructions. The ImmediateOutput instruction is only
used for refreshing the status of %QX0.0~%QX0.7 to external hardware output points. The
ImmediateOutput instruction does not control the TRUE or FALSE of %QX0.0~%QX0.7.

The Output parameter value 0~7 of the ImmediateOutput instruction corresponds
to %QX0.0~%QX0.7. Num represents the quantity of consecutive devices starting from the one
specified by Output. E.g. when Output value is 0 and Num is 2, it indicates that the status of %QX0.0
and %QX0.1 is refreshed to the external hardware output point.
 Precautions for Correct Use
The instruction is only used for the immediate refresh of local output points instead of extension output
points.
8-212
