8.11.7 ZONE
FB/FC
Explanation
Applicable
model
FC
ZONE is used for adding a bias value to the input value and the processing
result is output to Out.
DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
BiasN
Negative
bias value
Input
Negative bias
Depends on the data type of the
variable that the input parameter is
connected to.
In
Data to
control
Input
Data to control
Depends on the data type of the
variable that the input parameter is
connected to.
BiasP
Positive bias
value
Input
Positive bias
Depends on the data type of the
variable that the input parameter is
connected to.
Out
Processing
result
Output Processing result
Depends on the data type of the
variable that the output parameter is
connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
Bias
N
● ●
In
● ●
Bias
P
● ●
Out
● ●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation

The ZONE instruction adds the set bias value to the value of In and the processing result is output to
Out. When the value of In is a negative value, BiasN is the bias value. When the value of In is a
positive value, BiasP is the bias value.
ZONE
EN ENO
BiasN Out
BiasP
In
8-146
