DVP15MC11T Operation Manual
_8
8.10.3 ROL
FB/FC
Explanation Applicable model
FC
ROL is used to rotate left all bits of a variable or constant by the specified
number of bits and the result is output to Out.
DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
In
Data to
rotate
Input
The original data to rotate
left
Depends on the data type of the
variable that the input parameter is
connected to.
Num
Number of
bits
Input
The number of bits by
which the bits of the
original data are rotated
to the left
Depends on the data type of the
variable that the input parameter is
connected to.
Out Result Output
Result from rotating all
bits of the original data by
the number of bits
specified by Num to the
left
Depends on the data type of the
variable that the output parameter is
connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
In
●
● ● ● ● ● ● ●
Num
●
Out
The data type of Out must be the same as In.
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation
ROL is used to rotate all bits of the value of In by the number of bits specified by Num to the left and the
result is output to Out.
Via ROL, the bits shifted out of the left will shift to the null bits in the right one by one. When Num=2, all
bits of the value of In rotates by two bits to the left. The rotation method is that Bit0~Bit5 are shifted to
Bit2~Bit7 respectively, Bit 7 is shifted to Bit1 and Bit 6 is shifted to Bit0.
ROL
EN ENO
In Out
Num
8-128
