DVP15MC11T Operation Manual
_8
8.4.6 Swap
FB/FC
Explanation
Applicable
model
FC
Swap is used for swapping the high byte and low byte of a 16-bit value. DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
In
Input
signal
Input Data to swap 0~65535 for word data type
Out
Output
signal
Output Result 0~65535 for word data type
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
In
● ●
Out
● ●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation
The Swap instruction exchanges the high byte and low byte of the value of In and the result is output to
Out.

Programming Example
 The variable table and program
Variable name
Data type
Current value
Swap_EN
BOOL
TRUE
Swap_In
UINT
32768
Out1
UINT
128
Swap
EN ENO
In Out
1
Swap
EN ENO
In Out
Swap_EN
Swap_In Out1
8-26
