DVP15MC11T Operation Manual
11
1
11.5.5 Rotary-cut Instructions
11.5.5.1 APF_RotaryCut_Init
FB/FC Explanation Applicable model
FB
APF_RotaryCut_Init is used for initializing the radius of the rotary-cut
axis and feed axis, the cutting length, synchronous area and etc.
DVP15MC11T
 Input Parameters
Parameter name Function Data type
Valid range
(Default)
Validation timing
Execute
The instruction is
executed when Execute
changes from FALSE to
TRUE.
BOOL
TRUE or FALSE
(FALSE)
RotaryAxisRadius
The radius of the rotary
cut axis, i.e. the
distance from the center
of the rotary cut roller to
the knife.
LREAL
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
RotaryAxisKnifeNum
The number of knives of
the rotary cut axis, i.e.
the number of knives
mounted on the rotary
cut roller
USINT
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
FeedAxisRadius
The radius of the feed
axis; i.e. the radius
length of the feed roller
LREAL
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
CutLength
The cutting length of
material
LREAL
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
SyncStartPos
The start position of the
sync area, i.e. the
corresponding feed axis
position when the sync
area starts.
LREAL
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
SyncStopPos
The end position of the
sync area, i.e. the
corresponding feed axis
position when the sync
LREAL
Positive number
(The variable
value must be
set)
When Execute
changes from FALSE
to TRUE
APF_RotaryCut_Init
Execute
RotaryAxisRadius
Done
Busy
Error
ErrorID
RotaryAxisKnifeNum
FeedAxisRadius
CutLength
SyncStartPos
SyncStopPos
RotStartPos
RotaryCutID
FedStartPos
APF_RotaryCut_Init_instance
11-182
