Delta Electronics DVP15MC11T User Manual

Chapter 8 Logic Instructions
8_
8.3.3 RS
FB/FC
Explanation
Applicable
model
FB
RS is used for giving priority to the Reset input. DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
SET
Input
signal
Input
SET signal TRUE or FALSE
Reset
Input
signal
Input
Reset signal TRUE or FALSE
Q
Output
signal
Output Output signal TRUE or FALSE
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
SET
●
Reset
●
Q
●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation
When the SET and Reset inputs of RS are both TRUE, Reset is given the priority.

Programming Example
 The variable table and program
Variable name
Data type
Initial value
RS1
RS
RS1_EN
BOOL
FALSE
RS1_SET
BOOL
FALSE
RS1_Reset BOOL FALSE
RS1_Q BOOL
RS
EN ENO
SET
Q
RS_instance
Q
Reset
8-11
