Chapter 8 Logic Instructions
8_
8.3.4 SR
FB/FC
Explanation
Applicable
model
FB
SR is used for giving priority to the Set input. DVP15MC11T
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
SET
Input
signal
Input
SET signal TRUE or FALSE
Reset
Input
signal
Input
Reset signal TRUE or FALSE
Q
Output
signal
Output Output signal TRUE or FALSE
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL BYTE WORD DWORD LWORD USINT UINT UDINT ULINT SINT INT DINT LINT REAL LREAL TIME DATE TOD DT STRING
SET
●
Reset
●
Q
●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data type.
 Function Explanation
When the SET and Reset inputs of RS are both TRUE, SET is given the priority.
SR
EN ENO
SET
Q
SR_instance
Q
Reset
8-13
