1.2 Connecting a cable 31
Parallel Connection
When using a parallel connection, you must first install the optional Parallel Port and
connector conversion cable.
Important
• Parellel Port Kit (optional) and Gigabit Ethernet Board Card (optional) cannot be installed at the same
time.
.1. Switch the printer off.
2. Insert the connector conversion cable
included with the optional Parallel Port into
the interface connector on the printer.
3. Connect the other end of the connector
conversion cable to the connector on the
parallel cable. Then secure it using the
metal pieces on both sides of the
connector.
4. Plug the other end of the parallel cable into
your computer.
5. Switch the printer on.
Important
• Parallel Port Kit (Optional) and Gigabit Ethernet Board Card cannot be installed concurrently. If the
Parallel Port Kit (Optional) is installed, remove the card by reference to “ Removing the Parallel Port Kit
(Optional)” (P. 344).
To Next Page
