Furuno FV-110 User Manual

Keypad and menus of the ACU
5-48
5.4.3 The menu tree
In the menu tree you can see how the system has been configured. To enter satellite
information directly, use a connected PC and the web interface.
Figure 5-41: Antenna Control Unit, menu tree
MAIN
ANT
ANTENNA
MODEM
NETWORK
SATELLITE
EVENTS
POINTING
POLARIZATION
GNSS
HEADING
VERSIONS
SERIAL NUMBERS
EVENT
<EVENT 1>
<EVENT 2>
<EVENT 3>
<EVENT 4>
SAT
POSITION
RX POLARIZATION
TX POLARIZATION**
RX FREQUENCY
LNB LO **
TX FREQUENCY
BUC LO
NET
HOST NAME
PORT 1/2 IP
PORT 1/2 MASK
PORT 3 IP
PORT 3 MASK
PORT 4 IP
PORT 4 MASK
DEFAULT GATEWAY
ANT-2
RX POLARIZATION
TX POLARIZATION
ANT-1
ANTENNA STATE
ELEVATION
AZIMUTH
ANT-3
LATITUDE
LONGITUDE
FIX TYPE
MODEM
MODEM/TYPE
TX ENABLE
RX LOCK
SIGNAL LEVEL *
ANT-5
SW VERSION
ANT-6
ACU
Antenna
SAT
* for some modems
** for some antenna configurations
ANT-4
HEADING
