Keypad and menus of the ACU
5-51
Example: EVENT 1/4*: This is the first event out of a list of 4 and there has been a
change in the list. EVENT 1/4 will always be shown, the * indicates that
there has been a change.
5.4.4 Adjusting brightness of the display
To adjust the brightness do the following:
1. Press and hold OK for a short moment until Brightness XXX% is displayed (XXX is
the current brightness value).
2. Hold OK pressed + press for lighter or for darker display.
3. Release OK to leave the brightness menu.
SATELLITE menu Description
POSITION Position of the current satellite.
RX
POLARISATION
HORIZONTAL, VERTICAL.
TX
POLARIZATION
X-polarisation or Co-polarisation, auto-selected by VSAT
modem
RX FREQUENCY Ku band receiving frequency of the active satellite, auto-
selected by VSAT modem.
LNB LO Auto selected by VSAT modem.
TX FREQUENCY Transmission frequency, auto-selected by VSAT modem
BUC LO 12.8 GHz, system parameter
Table 5-23: SATELLITE menu of the ACU
EVENT menu Description
<EVENT> In this menu all active events are listed. Use
and to go
through the active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while
you are in the EVENTS menu, a * is shown in the upper left
corner of the display, next to the menu name. Press OK to update
the EVENTS list, the * will be removed.
A > means the event text is longer than the display. Press to > to
see the remaining text.
Table 5-24: EVENTS menu of the ACU
