Inmarsat G5 modem
C-30
LAN1
The ACU LAN1 is used to communicate with the Inmarsat G5 system. This interface
supports following commands:
C.8.4 ACU configuration
To set-up the ACU to work with an Inmarsat G5 modem, do as follows:
1. Add a modem profile with the Inmarsat G5 modem. See Modem profiles on page 5-22.
2. Add a satellite profile using the Inmarsat G5 modem profile just created. See Satellite
profiles on page 5-24.
3. Activate the satellite profile.
See also the configuration example in the following section.
[Get] commands ACU Response
G5: Get Current ACU
Status
$CACUS CACUS:ANTS#TRK:AGCL#68:TXL#1:HDG#YES:
BLOK#NO
G5: Get Current ACU
Values
$CACUV CACUV:AZIM#181.2:ELEV#26.8:RAZM#180.8:
POLN#0.7
G5:Request Current
Error Status
$RCES RCES:COMME#NOERROR:AZME#NOERROR:
ELME#NOERROR:CLME#NOERROR:
POLNME#NOERROR:GPSE#NOERROR:
PWRE#NOERROR:BUCE#NOERROR:LNBE#NOERROR
G5:Request Current
Values Status
$RCVS RXPOL#V:SKEW#0.0:MLOCK#ON:MAXINCL#0.0:
TXFREQ#955000:TXLO#12800
RCVS:LALO#N55.00-
E012.00:HEAD#1.7:SATP#11.0E:FREQ#1466900:
BAND#1:LNB#XPOL:TXPOL#H:
G5: Get Command $GC:ACUNS ACUNS:IP#192.168.1.1:MASK#255.255.255.0:
GW#0.0.0.0:DNS#0.0.0.0
Table C-11: LAN1 - [Get] commands
[Set] commands
G5: Set Command Modem Lock $SC:MLOCK#ON
G5: Set Command Modem No Lock $SC:MLOCK#OFF
G5: Send Values $SV:FREQ#1466900:SATP#42.0E:BAND#1:TXPOL#H:
RXPOL#V:LNB#XPOL:TXFREQ#955000:TXLO#12800:
SKEW#0.0:MAXINCL#0.0
Table C-12: LAN1 - [Set] commands
