A-1
Appendix A
Data sheets
A
A.1 VSAT LNB Data Sheet (physical LNB)
The following table shows the data of the LNBs which are fitted in the ADU.
The FV-110 is designed to make any Ku Band frequency in the range of 10.7 GHz to 12.75 GHz
available to a VSAT modem by allowing the user to select the LNB LO of his choice – without having
to exchange the physical LNBs in the ADU. This is achieved by the sophisticated single-cable solution
of the FV-110.
Please see A.1.1 for configuration information.
Interface Model Spec.
Input, Ku-
band
2-band WR75 waveguide
Output, IF 2-band F (50 Ohm)
LO type 2-band Locked to 10 MHz external reference over IF interface or ACU
internal
LO
frequencies
2-band 9.75, 10.75 GHz
Table A-1: Technical specifications for VSAT LNB 1/2
Parameter Condition/remark Unit Min. Typical Max.
Input frequency range VSAT GHz 10.7 12,75
Output (IF) frequency range 2-band MHz 950 2150
VSWR Input - 2.0 : 1
Output - 1.7 : 1
Noise Figure At 25 °C dB 0,8
LO stability Over temp. range kHz -10 0 10
Gain dB 60
Gain (relative) Over 500 MHz BW dB -2.0 0 2.0
Gain (relative) Over 36 MHz BW dB -0.5 0 0.5
External ref. freq. (input) Nominal MHz 10
Power supply voltage DC V 11.0 19.0
Supply current DC mA 350
Table A-2: Technical specifications for VSAT LNB 2/2
