Installation check list: ACU, connectors and wiring
6-3
6.2 Installation check list: ACU, connectors and wiring
Step Task
Verification and further
information
Done
1.
Check that the ACU is grounded correctly,
using the mounting bolts and washers.
See To ground the ACU on
page 2-27
and
Grounding and RF
protection on page F-1.
2.
Make sure you strain relieved the cables. See To install the ACU on
page 2-26.
3.
Make sure that the VSAT modem is
mounted close to the ACU.
See General mounting
considerations — VMU on
page 2-27.
4.
Check that the ADU antenna N-connector
is properly connected with the 50 Ohm RF
cable.
Visual inspection of the
cover plate at the bottom
of the ADU.
5.
Check that the ACU antenna N-connector
is properly connected with the 50 ohm RF
cable.
Visual inspection of the
connector panel of the
ACU.
6.
Check that the ACU's Rx Out is connected
to the VSAT modem’s Rx in using the
included 1 m F-F 75 ohm cable.
Visual inspection of the
connector panel of the
ACU and the VSAT
modem.
7.
Check that the ACU's Tx In is connected
to the VSAT modem's Tx out using the
included 1 m F-F 75 ohm cable.
Visual inspection of the
connector panel of the
ACU and the VSAT
modem.
Table 6-2: Installation check list: ACU, connectors and wiring
