FV-110 system
1-2
1.1.1 Above Deck Unit (ADU)
The FV-110 ADU is a 103 cm VSAT stabilised tracking antenna, consisting of a
suspended antenna with a standard global RF configuration. The ADU’s weight is
126,5 kg. It is stabilized by heavy duty vibration dampers in 3-axis (plus skew) and can be
used in environments with elevations of -25° to + 125°. The ADU is powered by the ACU
and protected by a radome.
Figure 1-2: Above Deck Unit (ADU)
