Serial setup for iDirect iNFINITI & Evolution
C-15
C.3.3 Configuration example (Serial)
Examples of modem profile and satellite configuration from the ACU web interface are
shown in the figures below. Add a modem profile (SETTINGS > Modem profiles) as
shown below.
Figure C-9: Modem profile, Serial (example)
Rx 10 MHz
The FV-110 can work either using the Rx or Tx 10 MHz reference
signals provided by the modem or using its own built-in 10 MHz
reference signal. It is recommended to use the Tx 10 MHz reference
signal from the modem. See also Modem profiles on page 5-22.
Tx 10 MHz The FV-110 needs the Tx 10 MHz reference signal in order to allow TX
ON.
Section in
option file
Description
Table C-6: Requirements for VSAT modem option file, Serial (Continued)
