Unpacking
2-2
2.1.2 Initial inspection
Inspect the shipping cartons and wooden box immediately upon receipt for evidence of
damage during transport. If the shipping material is severely damaged or water stained,
request that the carrier's agent be present when opening the cartons and wooden box. Save
all box packing material for future use.
After unpacking the system, i.e. removing the top and sides of the wooden box and
opening the cartons, inspect it thoroughly for hidden damage and loose components or
fittings. If the contents are incomplete, if there is mechanical damage or defect, or if the
system does not work properly, notify your dealer.
2.1.3 Tools needed
• Unbraco key (4 mm), included, mounted on a tool holder inside the radome.
Other tools that may be needed during the installation:
• Torx TX 20 to open the locks of the service hatch
• Wrench to fasten the mounting bolts for the ADU
• Wrench to fasten the N connector at the ADU
• PC and Internet browser
• Crimping tools
2.1.4 Transport of the antenna
During transport the antenna must be able to move freely inside the radome. You must
follow the instructions below to keep a valid warranty:
WARNING! To avoid electric shock, do not apply
power to the system if there is any sign of shipping
damage to any part of the front or rear panel or the outer
cover. Read the safety summary at the front of this
manual before installing or operating the system.
CAUTION!
Do not lock the antenna dish with the elevation
locking pin during transport.
Do not strap parts of the antenna.
These actions might cause damage to the antenna.
Damage due to actions listed above will void the
warranty.
