Calibration
5-9
The following table shows the error codes that might be displayed during a calibration.
Table 5-5: Possible error codes during calibration
Azimuth calibration with a service profile
1. Click SERVICE > Calibration.
2. Select the service profile in the drop down list Satellite. All profiles with the VSAT
modem Service & Calibration are displayed in the list. If there is no profile in the list
see To set up a service profile for calibration on page 5-9.
3. Click Start in the section Azimuth calibration and wait typically 5 minutes for the
calibration to finish. After finished calibration a message with the result of the
calibration is displayed.
5.2.3 To set up a service profile for calibration
If you do not want to use the automatic azimuth calibration or if you want to enter the
satellite parameters directly on the calibration page, use this calibration method. To
prepare for calibration you can set up a service profile for calibration.
To setup a service profile do as follows:
1. Open your Internet browser and enter the IP address of the ACU. The default IP
address is http://192.168.0.1.
2. Select SETTINGS > Satellite profiles > New entry. Enter the name of the satellite
profile for calibration (a name of your own choice).
Error
code
Explanation
1 The elevation of the selected satellite is too low. Select another satellite.
2 The elevation of the selected satellite is too high. Select another satellite.
4 The calibration values could not be saved. Possibly due to defective hardware.
5 The antenna could not point with sufficient precision. Check that the antenna is
mounted in a stable way. Other possible causes might be electrical or
mechanical faults.
6 No signal received. Check that there is free line of sight. Try again or try with
another satellite.
7 RF setup error, e.g. missing or invalid TX frequency.
8 Invalid satellite, e.g. satellite not visible.
