Installation of the ADU
2-18
2.3 Installation of the ADU
The ADU is shipped fully assembled. You have to install it on the mast and attach the
ADU cable.
Before installing the ADU read the following guidelines.
WARNING! Use a strong webbed sling with a belt to
lift the ADU without damaging the radome. Make sure
that the sling can carry the ADU’s weight126,5 kg (FV-
110).
WARNING! The ADU may be subject to swaying
motions in windy conditions. Always use tag lines to
stabilise the ADU during hoisting.
Figure 2-14: FV-110: Use of strong sling with a belt and tag lines for safe
hoisting
Tag lines
Webbed sling with belt
