Installation check list: Functional test in harbor
6-5
6.3 Installation check list: Functional test in harbor
Step Task Further information Done
1.
Check that the antenna is
tracking the satellite
The logon LED in the ACU
display must be steady green and
the display shows: TRACKING.
In the web interface check:
DASHBOARD:
System status: Tracking
2. Check that the VMU is in
lock and ready for Tx.
In the web interface check:
DASHBOARD > VSAT
MODEM > Signal level and RX
frequency show values.
3. Connect a user PC LAN
(not the service PC) to the
Internet LAN connector,
either on the LAN port 2 of
the ACU (only X5 VSAT
modem) or to the User
LAN connector on the
VMU.
Check the VSAT modem
documentation for details.
4. Open a DOS window and
type: ping 4.2.2.2.
Check that you get a response.
5. Open a web browser and
browse to
www.google.com.
Check that the web page is
downloaded.
6. If step 4 is successful and
step 5 is not then it seems
like the DNS is not
configured correctly.
Check the VSAT modem
documentation how to set up the
DNS server, “Obtain DNS server
address automatically” or enter
specific DNS server addresses.
Table 6-3: Installation check list: Functional test in harbour
