STM SatLink 2900 VSAT modem
C-22
C.6 STM SatLink 2900 VSAT modem
C.6.1 Interfaces and VSAT modem configuration
The following sections describe how to connect an ACU to an STM SatLink 2900 VSAT
modem. The STM SatLink 2900 and the FV-110 are fully integrated and require almost
no user setup.
STM SatLink 2900 software version required: 14.2.0 or higher.
Connections and login
1. Connect the ACU and STM SatLink 2900 with the following cables:
• Ethernet cable for TCP/IP data communication. Connect LAN A on the VSAT modem
to LAN 1 on the ACU.
• 75 Ohm RF cables F-F connectors for RX and TX frequencies
Figure C-17: Connecting STM SatLink 2900 VSAT modem to the ACU
2. Connect a PC to the modem via serial (setting: 38400, 8, N, 1) or telnet.
3. Login to the modem with the user name and password received from the VSAT service
provider.
Example: Login: root
Password: *******
SatLink 2900
- Main board ID 120265, Revision R4.0
- SW ID 120208, Revision 16.0.0 Build 46
4. Check that the modem has software version 14.2.0 or higher. Earlier modem software
versions are not supported.
