CG96 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
29F8 Digital Input 2 Trip Delay 1 50000 1 100ms F2 50
29F9 Digital Input 2 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 5
2A00
1st & 2nd Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
↓↓
2A05
11th & 12th Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
2A10 Digital Input 5 Type 0 1 1 - F116 0
2A11 Reserved
2A12 Digital Input 5 Alarm 0 2 1 - F115 0
2A13 Digital Input 5 Alarm Relays 0 6 1 - F113 0
2A14 Digital Input 5 Alarm Delay 1 50000 1 100ms F2 50
2A15 Digital Input 5 Alarm Events 0 1 1 - F103 0
2A16 Digital Input 5 Trip 0 2 1 - F115 0
2A17 Digital Input 5 Trip Relays 0 6 1 - F111 0
2A18 Digital Input 5 Trip Delay 1 50000 1 100ms F2 50
2A19 Digital Input 5 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 4
2A20
1st & 2nd Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
↓↓
2A25
11th & 12th Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
2A30 Digital Input 4 Type 0 1 1 - F116 0
2A31 Reserved
2A32 Digital Input 4 Alarm 0 2 1 - F115 0
2A33 Digital Input 4 Alarm Relays 0 6 1 - F113 0
2A34 Digital Input 4 Alarm Delay 1 50000 1 100ms F2 50
2A35 Digital Input 4 Alarm Events 0 1 1 - F103 0
2A36 Digital Input 4 Trip 0 2 1 - F115 0
2A37 Digital Input 4 Trip Relays 0 6 1 - F111 0
2A38 Digital Input 4 Trip Delay 1 50000 1 100ms F2 50
2A39 Digital Input 4 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 1
2A40
1st & 2nd Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
↓↓
2A45
11th & 12th Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
2A50 Digital Input 1 Type 0 1 1 - F116 0
2A51 Reserved
2A52 Digital Input 1 Alarm 0 2 1 - F115 0
2A53 Digital Input 1 Alarm Relays 0 6 1 - F113 0
2A54 Digital Input 1 Alarm Delay 1 50000 1 100ms F2 50
2A55 Digital Input 1 Alarm Events 0 1 1 - F103 0
2A56 Digital Input 1 Trip 0 2 1 - F115 0
2A57 Digital Input 1 Trip Relays 0 6 1 - F111 0
2A58 Digital Input 1 Trip Delay 1 50000 1 100ms F2 50
2A59 Digital Input 1 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 6
2A60
1st & 2nd Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
↓↓
2A65
11th & 12th Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
2A70 Digital Input 6 Type 0 1 1 - F116 0
2A71 Reserved
Table CG–10: MEMORY MAP (Sheet 51 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
