CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG107
F111
Unsigned 16 bit integer TRIP RELAYS
0none
1Trip
2Aux1
3Aux2
4Trip & Aux1
5Trip & Aux2
6Aux1 & Aux2
7 Trip & Aux1 & Aux2
F112
Unsigned 16 bit integer NOT DEFINED
0
1
F113
Unsigned 16 bit integer ALARM RELAYS
0None
1Alarm
2Aux1
3Aux2
4Alarm & Aux1
5Alarm & Aux2
6Aux1 & Aux2
7 Alarm & Aux1 & Aux2
F114
Unsigned 16 bit integer COUNTER TYPE
0Increment
1Decrement
F115
Unsigned 16 bit integer ALARM/TRIP TYPE SELECTION
0Off
1Latched
2Unlatched
F116
Unsigned 16 bit integer SWITCH TYPE
0Normally Open
1Normally Closed
F117
Unsigned 16 bit integer RESET MODE
0All Resets
1 Remote Reset Only
2Local Reset Only
Table CG–11: Memory Map Data Formats (Sheet 5 of 27)
CODE TYPE DEFINITION
