CG100 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
... Reserved
RRTD 3 – TEST ANALOG OUTPUTS
2BC0 Force Analog Outputs 0 1 1 - F126 0
2BC1 Analog Output 1 Forced Value 0 100 1 % range F1 0
2BC2 Analog Output 2 Forced Value 0 100 1 % range F1 0
2BC3 Analog Output 3 Forced Value 0 100 1 % range F1 0
2BC4 Analog Output 4 Forced Value 0 100 1 % range F1 0
... Reserved
RRTD 4 – TEST ANALOG OUTPUTS
2BD0 Force Analog Outputs 0 1 1 - F126 0
2BD1 Analog Output 1 Forced Value 0 100 1 % range F1 0
2BD2 Analog Output 2 Forced Value 0 100 1 % range F1 0
2BD3 Analog Output 3 Forced Value 0 100 1 % range F1 0
2BD4 Analog Output 4 Forced Value 0 100 1 % range F1 0
... Reserved
RRTD 1 – DIGITAL COUNTER
2BE0 First Character of Counter Name 32 127 1 - F1 “G”
2BEC First Character of Counter Unit Name 32 127 1 - F1 ‘U’
2BF2 Counter Type 0 1 1 - F114 0
2BF3 Digital Counter Alarm 0 2 1 - F115 0
2BF4 Assign Alarm Relays 0 6 1 - F113 0
2BF5 Counter Alarm Level 0 65535 1 - F1 100
2BF7 Reserved - - - - - -
2BF8 Record Alarms as Events 0 1 1 - F103 0
... Reserved
RRTD 2 – DIGITAL COUNTER
2C00 First Character of Counter Name 32 127 1 - F1 “G”
2C0C First Character of Counter Unit Name 32 127 1 - F1 ‘U’
2C12 Counter Type 0 1 1 - F114 0
2C13 Digital Counter Alarm 0 2 1 - F115 0
2C14 Assign Alarm Relays 0 6 1 - F113 0
2C15 Counter Alarm Level 0 65535 1 - F1 100
2C17 Reserved - - - - - -
2C18 Record Alarms as Events 0 1 1 - F103 0
... Reserved
RRTD 3 – DIGITAL COUNTER
2C20 First Character of Counter Name 32 127 1 - F1 “G”
2C2C First Character of Counter Unit Name 32 127 1 - F1 ‘U’
2C32 Counter Type 0 1 1 - F114 0
2C33 Digital Counter Alarm 0 2 1 - F115 0
2C34 Assign Alarm Relays 0 6 1 - F113 0
2C35 Counter Alarm Level 0 65535 1 - F1 100
2C37 Reserved - - - - - -
2C38 Record Alarms as Events 0 1 1 - F103 0
... Reserved
RRTD 4 – DIGITAL COUNTER
2C40 First Character of Counter Name 32 127 1 - F1 “G”
2C4C First Character of Counter Unit Name 32 127 1 - F1 ‘U’
2C52 Counter Type 0 1 1 - F114 0
2C53 Digital Counter Alarm 0 2 1 - F115 0
2C54 Assign Alarm Relays 0 6 1 - F113 0
2C55 Counter Alarm Level 0 65535 1 - F1 100
2C57 Reserved - - - - - -
2C58 Record Alarms as Events 0 1 1 - F103 0
... Reserved
EVENT RECORDER / TRACE MEMORY / MOTOR START DATA LOGGER (ADDRESSES 3000 TO 3FFF)
EVENT RECORDER
3000 Event Recorder Last Reset (2 words) N/A N/A N/A N/A F18 N/A
3002 Total Number of Events Since Last Clear 0 65535 1 N/A F1 0
Table CG–10: MEMORY MAP (Sheet 55 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
