GE 369 User Manual

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG93
2899 Digital Input 5 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 1 – DIGITAL INPUT 4
28A0
1st & 2nd Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
↓↓
28A5
11th & 12th Character of Digital Input 4
Name
32 127 1 - F22 ’GE’
28B0 Digital Input 4 Type 0 1 1 - F116 0
28B1 Reserved
28B2 Digital Input 4 Alarm 0 2 1 - F115 0
28B3 Digital Input 4 Alarm Relays 0 6 1 - F113 0
28B4 Digital Input 4 Alarm Delay 1 50000 1 100ms F2 50
28B5 Digital Input 4 Alarm Events 0 1 1 - F103 0
28B6 Digital Input 4 Trip 0 2 1 - F115 0
28B7 Digital Input 4 Trip Relays 0 6 1 - F111 0
28B8 Digital Input 4 Trip Delay 1 50000 1 100ms F2 50
28B9 Digital Input 4 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 1 – DIGITAL INPUT 1
28C0
1st & 2nd Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
↓↓
28C5
11th & 12th Character of Digital Input 1
Name
32 127 1 - F22 ’GE’
28D0 Digital Input 1 Type 0 1 1 - F116 0
28D1 Reserved
28D2 Digital Input 1 Alarm 0 2 1 - F115 0
28D3 Digital Input 1 Alarm Relays 0 6 1 - F113 0
28D4 Digital Input 1 Alarm Delay 1 50000 1 100ms F2 50
28D5 Digital Input 1 Alarm Events 0 1 1 - F103 0
28D6 Digital Input 1 Trip 0 2 1 - F115 0
28D7 Digital Input 1 Trip Relays 0 6 1 - F111 0
28D8 Digital Input 1 Trip Delay 1 50000 1 100ms F2 50
28D9 Digital Input 1 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 1 – DIGITAL INPUT 6
28E0
1st & 2nd Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
↓↓
28E5
11th & 12th Character of Digital Input 6
Name
32 127 1 - F22 ’GE’
28F0 Digital Input 6 Type 0 1 1 - F116 0
28F1 Reserved
28F2 Digital Input 6 Alarm 0 2 1 - F115 0
28F3 Digital Input 6 Alarm Relays 0 6 1 - F113 0
28F4 Digital Input 6 Alarm Delay 1 50000 1 100ms F2 50
28F5 Digital Input 6 Alarm Events 0 1 1 - F103 0
28F6 Digital Input 6 Trip 0 2 1 - F115 0
28F7 Digital Input 6 Trip Relays 0 6 1 - F111 0
28F8 Digital Input 6 Trip Delay 1 50000 1 100ms F2 50
28F9 Digital Input 6 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 1 – DIGITAL INPUT 3
2900
1st & 2nd Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
↓↓
2905
11th & 12th Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
2910 Digital Input 3 Type 0 1 1 - F116 0
2911 Reserved
2912 Digital Input 3 Alarm 0 2 1 - F115 0
Table CG–10: MEMORY MAP (Sheet 48 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
