CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG69
18B9 Enable RTD #10 Trip Voting 0 13 1 - F122 1
18BA Local RTD #10 Trip Relays 0 7 1 - F111 1
18BB Local RTD #10 Trip Level 1 200 1 °C F1 130
18BC Local RTD #10 RTD Type 0 3 1 - F120 0
18C0 First Character of Local RTD #10 Name 32 127 1 - F1 ’R’
↓↓
18C3 8th Character of RTD #10 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #11
18D0 Local RTD #11 Application 0 4 1 - F121 0
18D1 Local RTD #11 High Alarm 0 2 1 - F115 0
18D2 Local RTD #11 High Alarm Relays 0 7 1 - F113 2
18D3 Local RTD #11 High Alarm Level 1 200 1 °C F1 130
18D4 Local RTD #11 Alarm 0 2 1 - F115 0
18D5 Local RTD #11 Alarm Relays 0 7 1 - F113 1
18D6 Local RTD #11 Alarm Level 1 200 1 °C F1 130
18D7 Record RTD #11 Alarm Events 0 1 1 - F103 0
18D8 Local RTD #11 Trip 0 2 1 - F115 0
18D9 Enable RTD #11 Trip Voting 0 13 1 - F122 1
18DA Local RTD #11 Trip Relays 0 7 1 - F111 1
18DB Local RTD #11 Trip Level 1 200 1 °C F1 130
18DC Local RTD #11 RTD Type 0 3 1 - F120 0
18E0 First Character of Local RTD #11 Name 32 127 1 - F1 ’R’
↓↓
18E3 8th Character of Local RTD #11 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #12
18F0 Local RTD #12 Application 0 4 1 - F121 0
18F1 Local RTD #12 High Alarm 0 2 1 - F115 0
18F2 Local RTD #12 High Alarm Relays 0 7 1 - F113 2
18F3 Local RTD #12 High Alarm Level 1 200 1 °C F1 130
18F4 Local RTD #12 Alarm 0 2 1 - F115 0
18F5 Local RTD #12 Alarm Relays 0 7 1 - F113 1
18F6 Local RTD #12 Alarm Level 1 200 1 °C F1 130
18F7 Record RTD #12 Alarms as Events 0 1 1 - F103 0
18F8 Local RTD #12 Trip 0 2 1 - F115 0
18F9 Enable RTD #12 Trip Voting 0 13 1 - F122 1
18FA Local RTD #12 Trip Relays 0 7 1 - F111 1
18FB Local RTD #12 Trip Level 1 200 1 °C F1 130
18FC Local RTD #12 RTD Type 0 3 1 - F120 0
1900 First Character of Local RTD #12 Name 32 127 1 - F1 ’R’
↓↓
1903 8th Character of Local RTD #12 Name 32 127 1 - F1 " "
... Reserved
OPEN RTD ALARM
1B20 Open RTD Alarm 0 2 1 - F115 0
1B21 Assign Alarm Relays 0 7 1 - F113 1
1B22 Open RTD Alarm Events 0 1 1 - F103 0
SHORT/LOW TEMPERATURE RTD ALARM
1B23 Short / Low Temp RTD Alarm 0 2 1 - F115 0
1B24 Assign Alarm Relays 0 7 1 - F113 1
1B25 Short / Low Temp Alarm Events 0 1 1 - F103 0
... Reserved - - - - - -
LOSS OF REMOTE RTD COMMUNICATIONS
1B30 Loss RRTD Comm Alarm 0 2 1 - F115 0
1B31 Loss RRTD Comm Alarm Relays 0 7 1 - F113 1
1B32 Loss RRTD Comm Alarm Events 0 1 1 - F103 0
... Reserved
Table CG–10: MEMORY MAP (Sheet 24 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT

GE 369 Specifications

General

Current Rating	5A
Frequency	50/60 Hz
Mounting	Panel Mount
Protection Functions	Overcurrent, Undervoltage
Type	Digital protective relay
Operating Temperature	-20°C to 60°C
