CG82 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
2348 RRTD 2 - RTD #11 Trip 0 2 1 - F115 0
2349 Enable RRTD 2 - RTD #11 Trip Voting 0 13 1 - F122 1
234A RRTD 2 - RTD #11 Trip Relays 0 7 1 - F111 1
234B RRTD 2 - RTD #11 Trip Level 1 200 1 °C F1 130
234C RRTD 2 - RTD #11 RTD Type 0 3 1 - F120 0
2350 First Character of RRTD 2 - RTD #11 Name 32 127 1 - F1 ’R’
↓↓
2353 8th Character of RRTD 2 - RTD #11 Name 32 127 1 - F1 ’’
... Reserved
RRTD 2 – RTD #12
2360 RRTD 2 - RTD #12 Application 0 4 1 - F121 0
2361 RRTD 2 - RTD #12 High Alarm 0 2 1 - F115 0
2362 RRTD 2 - RTD #12 High Alarm Relays 0 7 1 - F113 2
2363 RRTD 2 - RTD #12 High Alarm Level 1 200 1 °C F1 130
2364 RRTD 2 - RTD #12 Alarm 0 2 1 - F115 0
2365 RRTD 2 - RTD #12 Alarm Relays 0 7 1 - F113 1
2366 RRTD 2 - RTD #12 Alarm Level 1 200 1 °C F1 130
2367
Record RRTD 2 - RTD #12 Alarms as
Events
0 1 1 - F103 0
2368 RRTD 2 - RTD #12 Trip 0 2 1 - F115 0
2369 Enable RRTD 2 - RTD #12 Trip Voting 0 13 1 - F122 1
236A RRTD 2 - RTD #12 Trip Relays 0 7 1 - F111 1
236B RRTD 2 - RTD #12 Trip Level 1 200 1 °C F1 130
236C RRTD 2 - RTD #12 RTD Type 0 3 1 - F120 0
2370 First Character of RRTD 2 - RTD #12 Name 32 127 1 - F1 ’R’
↓↓
2373 8th Character of RRTD 2 - RTD #12 Name 32 127 1 - F1 " "
... Reserved
RRTD 2 – OPEN RTD ALARM
2380 RRTD B - Open RTD Alarm 0 2 1 - F115 0
2381 RRTD B - Assign Alarm Relays 0 7 1 - F113 1
2382 RRTD B - Open RTD Alarm Events 0 1 1 - F103 0
RRTD 2 – SHORT/LOW TEMPERATURE RTD ALARM
2383 RRTD B - Short / Low Temp RTD Alarm 0 2 1 - F115 0
2384 RRTD B - Assign Alarm Relays 0 7 1 - F113 1
2385 RRTD B - Short / Low Temp Alarm Events 0 1 1 - F103 0
... Reserved - - - - - -
RRTD 3 – RTD #1
2400 RRTD 3 - RTD #1 Application 0 4 1 - F121 0
2401 RRTD 3 - RTD #1 High Alarm 0 2 1 - F115 0
2402 RRTD 3 - RTD #1 High Alarm Relays 0 7 1 - F113 2
2403 RRTD 3 - RTD #1 High Alarm Level 1 200 1 °C F1 130
2404 RRTD 3 - RTD #1 Alarm 0 2 1 - F115 0
2405 RRTD 3 - RTD #1 Alarm Relays 0 7 1 - F113 1
2406 RRTD 3 - RTD #1 Alarm Level 1 200 1 °C F1 130
2407 Record RRTD 3 - RTD #1 Alarms as Events 0 1 1 - F103 0
2408 RRTD 3 - RTD #1 Trip 0 2 1 - F115 0
2409 Enable RRTD 3 - RTD #1 Trip Voting 0 13 1 - F122 1
240A RRTD 3 - RTD #1 Trip Relays 0 7 1 - F111 1
240B RRTD 3 - RTD #1 Trip Level 1 200 1 °C F1 130
240C RRTD 3 - RTD #1 RTD Type 0 3 1 - F120 0
2410 First Character of RRTD 3 - RTD #1 Name 32 127 1 - F1 ’R’
↓↓
2413 8th Character of RRTD 3 - RTD #1 Name 32 127 1 - F1 " "
2414 Reserved
RRTD 3 – RTD #2
2420 RRTD 3 - RTD #2 Application 0 4 1 - F121 0
2421 RRTD 3 - RTD #2 High Alarm 0 2 1 - F115 0
2422 RRTD 3 - RTD #2 High Alarm Relays 0 7 1 - F113 2
2423 RRTD 3 - RTD #2 High Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 37 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
